How to Tape Pickleball Court Lines (and When Tape Is the Wrong Answer)
By the PickleCourt USA team · Updated
The short answer
A regulation pickleball court is a 20 x 44 ft rectangle measured to the outside edge of the lines, with 2-inch lines that sit inside that boundary. Mark one sideline, square the first corner with a 3-4-5 triangle (12 ft, 16 ft, 20 ft), set the other corners, and check that both diagonals measure about 48 ft 4 in. Then mark the kitchen lines 7 ft from the net and the centerlines 10 ft from the sidelines, and tape the inside of every mark. Before any of that, get permission: the maple flooring industry association does not recommend any adhesive tape on finished gym floors.
The measurements that matter
Everything here comes from Section 3 of the USA Pickleball Official Rulebook. Rule 3.A.1 sets the court at 20 feet wide and 44 feet long for both singles and doubles. Rule 3.A.2 says court measurements are made to the outside edge of the perimeter and non-volley zone lines, which is the single most common thing people get wrong with tape. Rule 3.A.4.e says all lines should be 2 inches wide, the same color, and clearly contrasting with the surface. Rule 3.A.4.c puts the non-volley zone (the kitchen) 7 feet from the net on each side, and says the lines that bound it are part of the zone.
The net is not a line you tape, but it controls where the kitchen lines go. Rule 3.B.2 puts net posts 22 feet apart, inside to inside, and Rules 3.B.6 and 3.B.7 set the net at 36 inches high at the sidelines and 34 inches at the center. If you're choosing a portable net for a taped court, our portable nets and post systems comparison covers which freestanding systems hold those heights.
| Line | Where it goes | Taping tip |
|---|---|---|
| Baselines (2) | The two 20 ft ends of the court. Outer edge of the tape sits on the 44 ft mark at each end. | Tape these after the sidelines so the corners overlap cleanly. |
| Sidelines (2) | The two 44 ft sides. Outer edge of the tape sits on the 20 ft width mark. | Snap or stretch a string line; don't eyeball 44 ft. |
| Non-volley zone (kitchen) lines (2) | Parallel to the net, 7 ft from the net on each side, across the full 20 ft width. | The 7 ft is measured to the outside edge of the kitchen line (the edge away from the net). |
| Centerlines (2) | From each kitchen line to its baseline, splitting the 15 ft service area into right and left service courts. | Center the 2 in tape on the 10 ft mark from either sideline's outer edge. |
| Net line (reference only) | Across the middle, 22 ft from each baseline. The net sits here; there is no painted net line in the rules. | Mark it lightly as your reference for measuring the kitchen lines. |
Before you buy tape: check the space and the floor
A taped court needs more room than its lines. Rule 3.A.3 sets the minimum playing surface at 30 x 60 feet, and the rulebook recommends 34 x 64 feet for new construction and tournament play. That run-off is where players chase lobs and wide dinks, so walls, bleachers, poles and parked cars inside it are a safety problem, not just an inconvenience. Our court space requirements guide walks through fitting one or more courts into a room or lot.
The floor matters as much as the footprint. Taping works best on smooth, clean, dry concrete or sport surfaces where the owner has said yes. It works badly, or not at all, on several common surfaces:
- Finished maple gym floors. The Maple Flooring Manufacturers Association (MFMA) says it does not recommend masking, theatrical, construction, electrical, duct, adhesive or any other kind of tape for temporary court boundaries on a finished maple floor. Its reasons: removing tape is likely to peel away layers of finish, most tapes have different traction from the finish (which affects starting, stopping and pivoting), and adhesive resins can etch or stain the finish or the wood below.
- Grass, dirt and gravel. Tape won't stick, and the bigger issue is the bounce. Soft ground needs a hard base before any court; see our PickleDeck sub-surface page.
- Rough or dusty asphalt. Tape lifts at the edges and tears when players slide. Sweep and dry the surface, and expect to replace sections.
- Carpet and decorative floors. Ballrooms, convention carpet, sealed decorative concrete and painted floors may not allow adhesive at all. Ask the venue for its rules in writing.
Can't tape the floor?
A roll-out court arrives with regulation lines printed at manufacture, so there's nothing to measure, and indoor installs start with a floor-protection layer instead of 140-plus feet of tape lines. Tell us the space and we'll quote it. Quote only, no made-up price list.
Laying out and taping a court, step by step
You'll need a 50 ft or 100 ft tape measure, string or a chalk line, a pencil or removable markers for the corners, 2-inch tape in a color that contrasts with the floor, and ideally a second person to hold the far end of the tape.
Confirm you're allowed to tape, and on what
Get written permission from whoever owns the floor or pavement, and ask what tape they allow. Gyms, ballrooms, rental halls and HOAs often have rules. If the answer is 'nothing adhesive,' skip to the alternatives below.
Check the total space, not just the court
The court is 20 x 44 ft, but USA Pickleball's minimum playing surface is 30 x 60 ft, with 34 x 64 ft recommended for new construction and tournament play. Measure the clear area, then center the court inside it.
Mark the first sideline and its two corners
Pick the longest straight reference you have (a wall, a parking stall line, a floor seam), measure off it evenly at both ends, and stretch a string. Mark the two corners of one sideline exactly 44 ft apart.
Square the first baseline with a 3-4-5 triangle
From one corner, measure 12 ft along the sideline and make a mark. Then find the point 16 ft out from the corner that is exactly 20 ft from that 12 ft mark. That gives a 90-degree corner (a 3-4-5 triangle scaled by four). Extend that line to 20 ft for the baseline.
Set the last corner and check the diagonals
Measure 44 ft along the second sideline and 20 ft across the second baseline to find the fourth corner. Then measure both diagonals corner to corner. Each should be about 48 ft 4 in. If they differ, nudge the far corners until they match.
Mark the net line, kitchen lines and centerlines
Mark the midpoint of each sideline (22 ft) for the net. Measure 7 ft from it toward each baseline for the kitchen lines, then mark 10 ft from either sideline's outer edge along the kitchen line and baseline for the centerlines.
Tape the inside of your marks
Lay sidelines and baselines with the outer edge of the tape on your marks, kitchen lines with their outer edge at 7 ft, and centerlines centered on the 10 ft mark. Press tape down along its full length and check corners once more before anyone plays.
Why squaring the court matters more than the tape
A court that is an inch long on one sideline and an inch short on the other looks fine from the baseline and still produces bad calls on every deep ball in one corner. That's why the diagonal check is the step not to skip. In a true rectangle the two diagonals are equal. For 20 x 44 ft, measured outside corner to outside corner, each diagonal works out to about 48 ft 4 in (the square root of 20² + 44², or 2,336). If you only have a 30 ft tape, check each half court instead: 20 x 22 ft gives a diagonal of about 29 ft 9 in.
The 3-4-5 method is the other half of the trick. Any triangle whose sides are in the ratio 3:4:5 has a right angle opposite the longest side. Scaling it by four gives 12, 16 and 20 ft, which conveniently uses the court width as the long side. On a big empty floor it is more reliable than lining up with a wall, because walls are often not square to each other.
The kitchen line and centerline mistakes we see most
Kitchen lines cause the most arguments on taped courts. Because the 7 ft is measured from the net to the outside edge of the line, the 2-inch tape lies between 6 ft 10 in and 7 ft from the net. Lay it the other way and the kitchen grows by two inches, which players who live at the line will notice. The rulebook also says the kitchen line is part of the zone, so a foot on the tape during a volley is a fault; another reason the tape needs to be straight and firmly stuck down.
Centerlines are the one place the tape is centered on the measurement. The rulebook describes a 10 ft mark from the outside edge of each sideline for the center strap position, which is the court's midline, so the 2-inch centerline straddles it, from 9 ft 11 in to 10 ft 1 in. Run each centerline only from the kitchen line to the baseline; there is no centerline inside the kitchen.
Choosing tape
Look for tape that is exactly 2 inches wide, rated for the surface you're on (indoor floor versus outdoor pavement), and in a color that contrasts clearly with the floor, as Rule 3.A.4.e requires. Use one color for every line. On a floor that already has basketball or volleyball lines, choose a color none of the other sports use so players can pick out pickleball lines at a glance.
Read the product's removal guidance and test a small, hidden spot first, especially on anything painted, sealed or finished. Leave it for as long as the court will be down and pull it up the way you will on the last day. If it lifts finish, leaves residue or tears, you have your answer before it's 140-plus feet of tape. Non-adhesive lay-down line sets are another option for floors where adhesive isn't allowed; they don't give you a flat court, but they avoid residue.
Taping outdoors: driveways and parking lots
Outdoors, you're fighting heat, dust, dew and cars. Sweep and blow the surface clean, tape when the pavement is dry, and press the tape down hard along its whole length. Expect edges to lift where players slide and where water collects. If the court will stay down, many owners move on from tape quickly. Our driveway pickleball court guide covers slope, drainage and the surface options for a home court that gets used every week.
When tape is the wrong answer
Tape is a good tool for a one-off game on a surface you control. It stops being the right tool when you have to re-measure and re-tape the same court over and over, when the floor isn't yours to tape, or when guests, clients or members expect a finished-looking court. Those are the situations roll-out courts are built for: the lines are printed at manufacture, so every setup is regulation without a tape measure, and indoor installs on finished floors normally start with a floor-protection layer, with the court secured at its perimeter instead of lines taped across the whole playing area.
If you're comparing options, our portable and temporary pickleball court guide puts tape and a net, interlocking tiles and roll-out courts side by side, and pickleball on a gym floor covers schools and rec centers that need courts without touching the maple.
Taping pickleball court lines: FAQs
How wide should pickleball court tape be?
Use 2-inch tape. The USA Pickleball rulebook (Rule 3.A.4.e) says all lines should be 2 inches wide, the same color, and clearly contrasting with the playing surface. Wider tape changes where the in/out edge sits; narrower tape is harder to see and harder to call.
Do the lines go inside or outside the 20 x 44 ft measurement?
Inside. Rule 3.A.2 says court measurements are made to the outside edge of the perimeter and non-volley zone lines, so the outer edge of each sideline and baseline tape is the 20 x 44 boundary. Lay tape on the inside of your measured marks, not centered on them.
What are the diagonal measurements for squaring a pickleball court?
For a 20 x 44 ft rectangle measured to the outside corners, both full-court diagonals should be about 48 ft 4 in (the square root of 20 squared plus 44 squared). Each half court (20 x 22 ft) has a diagonal of about 29 ft 9 in. If your two diagonals don't match, the court isn't square; adjust before you tape.
Can I put tape on a gym floor for pickleball?
Ask the facility first, and on a finished maple floor expect a no. The Maple Flooring Manufacturers Association says it does not recommend masking, construction, electrical, duct, adhesive or any other tape for temporary court boundaries on finished maple, because removal can peel the finish, tape changes traction, and adhesive resins can stain or etch the floor. A floor cover or a roll-out court with printed lines avoids the problem.
How long does it take to tape a pickleball court?
It depends on the surface, the crew and how carefully you measure. Plan for measuring and squaring to take longer than laying tape, and for two people to work faster and more accurately than one. If you'll be re-taping often, time your first few layouts and plan around your own numbers.
Is a roll-out court better than taping lines?
For a one-off game on a surface you're allowed to tape, tape is cheaper. For repeated setups, events, finished floors you can't tape, or anywhere you want regulation lines in the same place every time, a roll-out court with lines printed at manufacture removes the measuring and the lines taped across the floor. Pricing is quote-based because it depends on court count, surface and accessories.
